A Generalized Multiscale Iterative Finite Element Method for Parameterized Dual-Continuum Models

Ma Lingling; Song Xiaoyan

doi:10.21656/1000-0887.460121

Volume 47 Issue 7

Jul. 2026

Turn off MathJax

Article Contents

Article Navigation > Applied Mathematics and Mechanics > 2026 > 47(7): 936-958

Ma Lingling, Song Xiaoyan. A Generalized Multiscale Iterative Finite Element Method for Parameterized Dual-Continuum Models[J]. Applied Mathematics and Mechanics, 2026, 47(7): 936-958. doi: 10.21656/1000-0887.460121

Citation:

PDF( 6815 KB)

A Generalized Multiscale Iterative Finite Element Method for Parameterized Dual-Continuum Models

doi: 10.21656/1000-0887.460121

Ma Lingling^1
,,
Song Xiaoyan^{2
,
,}

1.
Hunan Provincial University Key Laboratory for Big Data Analysis and Application, School of Mathematics and Statistics, Hunan First Normal University, Changsha 410205, P. R. China
2.
School of Mathematics and Statistics, Hunan University of Technology and Business, Changsha 410205, P. R. China

Received Date: 2025-06-11
Rev Recd Date: 2026-06-11
Publish Date: 2026-07-01

Abstract

Abstract

The parameterized dual-continuum model plays a significant theoretical and practical role in various subsurface geological modeling applications. This model effectively captures the highly heterogeneous, high-contrast, and multiscale structural features of geological formations, while also exhibiting considerable uncertainty. To address the numerical challenges posed by such complex models, adopting appropriate model reduction techniques has become a key approach to improving computational efficiency while maintaining solution accuracy. Herein an iterative solution strategy was proposed based on the uncoupled generalized multiscale finite element method (GMsFEM) for the parameterized dual-continuum model. The original parameter-dependent model was reformulated as a new one consisting of multiscale diffusion coefficients and transfer functions (both parameter-independent), along with a parameter-dependent source term. The proposed iterative method was divided into offline and online stages. In the offline stage, multiscale basis functions were constructed in each coarse grid block based on deterministic multiscale parameters to generate a reduced-order space. In the online stage, the model was solved efficiently within the reduced space with an iterative scheme. A major advantage of this method lies in the fact that, once the multiscale basis space is constructed offline, each online iteration can leverage efficient direct solvers and reuse matrix inverses, thus significantly reducing computational costs. Furthermore, the convergence of the proposed iterative method was analyzed. Finally, numerical experiments on the parameterized dual-continuum model were conducted to demonstrate the effectiveness and efficiency of the multiscale-based iterative approach, and validate the theoretical convergence results.
- dual continuum model,
- generalized multiscale finite element method,
- iterative method,
- uncertainty quantification

FullText(HTML)

References(41)

References

[1]	Yao J, Huang Z Q. Fractured Vuggy Carbonate Reservoir Simulation[M]. 2nd ed. Springer, 2017.
[2]	Biermans M B G M, Dijkema K M, De Vries D A. Water movement in porous media towards an ice front[J]. Journal of Hydrology, 1978, 37 (1/2): 137-148.
[3]	Harris C C. Sedimentation rates, fluidization and flow through porous media[J]. Nature, 1959, 184 (4687): 716. doi: 10.1038/184716a0
[4]	李树光, 曲凯. 多孔介质中单相气体局部流动的均质化建模[J]. 应用数学和力学, 2024, 45 (2): 175-183. doi: 10.21656/1000-0887.440246 Li Shuguang, Qu Kai. Homogenization modeling of single-phase gas local flow in porous media[J]. Applied Mathematics and Mechanics, 2024, 45 (2): 175-183. (in Chinese) doi: 10.21656/1000-0887.440246
[5]	苏成, 罗俊哲, 许秩. 多孔结构多尺度随机振动分析的渐近均匀化-时域显式法[J]. 应用数学和力学, 2023, 44 (1): 1-11. doi: 10.21656/1000-0887.430116 Su Cheng, Luo Junzhe, Xu Zhi. An asymptotic-homogenization explicit time-domain method for random multiscale vibration analysis of porous material structures[J]. Applied Mathematics and Mechanics, 2023, 44 (1): 1-11. (in Chinese) doi: 10.21656/1000-0887.430116
[6]	Han J H, Wang M, Bai P, et al. Dendrite suppression by shock electrodeposition in charged porous media[J]. Scientific Reports, 2016, 6: 28054. doi: 10.1038/srep28054
[7]	Hayat T, Hussain Z, Alsaedi A, et al. Numerical study for slip flow of carbon-water nanofluids[J]. Computer Methods in Applied Mechanics and Engineering, 2017, 319: 366-378. doi: 10.1016/j.cma.2017.02.021
[8]	Baca R G, Arnett R C, Langford D W. Modelling fluid flow in fractured-porous rock masses by finite-element techniques[J]. International Journal for Numerical Methods in Fluids, 1984, 4 (4): 337-348. doi: 10.1002/fld.1650040404
[9]	Eikemo B, Lie K A, Eigestad G T, et al. Discontinuous Galerkin methods for advective transport in single-continuum models of fractured media[J]. Advances in Water Resources, 2009, 32 (4): 493-506. doi: 10.1016/j.advwatres.2008.12.010
[10]	Bogdanov II, Mourzenko V V, Thovert J F, et al. Two-phase flow through fractured porous media[J]. Physical Review E, 2003, 68 (2): 026703. doi: 10.1103/PhysRevE.68.026703
[11]	Granet S, Fabrie P, Lemonnier P, et al. A two-phase flow simulation of a fractured reservoir using a new fissure element method[J]. Journal of Petroleum Science and Engineering, 2001, 32 (1): 35-52. doi: 10.1016/S0920-4105(01)00146-2
[12]	Geiger S, Matthäi S, Niessner J, et al. Black-oil simulations for three-component, three-phase flow in fractured porous media[J]. SPE Journal, 2009, 14 (2): 338-354. doi: 10.2118/107485-PA
[13]	Matthai S K, Mezentsev A A, Belayneh M. Finite element-node-centered finite-volume two-phase-flow experiments with fractured rock represented by unstructured hybrid-element meshes[J]. SPE Reservoir Evaluation & Engineering, 2007, 10 (6): 740-756.
[14]	Barenblatt G I, Zheltov I P, Kochina I N. Basic concepts in the theory of seepage of homogeneous liquids in fissured rocks[strata] [J]. Journal of Applied Mathematics and Mechanics, 1960, 24 (5): 1286-1303. doi: 10.1016/0021-8928(60)90107-6
[15]	Wu Y S, Pruess K. A multiple-porosity method for simulation of naturally fractured petroleum reservoirs[J]. SPE Reservoir Engineering, 1988, 3 (1): 327-336. doi: 10.2118/15129-PA
[16]	Yan B, Alfi M, An C, et al. General multi-porosity simulation for fractured reservoir modeling[J]. Journal of Natural Gas Science and Engineering, 2016, 33: 777-791. doi: 10.1016/j.jngse.2016.06.016
[17]	Akkutlu I Y, Efendiev Y, Vasilyeva M, et al. Multiscale model reduction for shale gas transport in a coupled discrete fracture and dual-continuum porous media[J]. Journal of Natural Gas Science and Engineering, 2017, 48: 65-76. doi: 10.1016/j.jngse.2017.02.040
[18]	Cheung S W, Chung E T, Efendiev Y, et al. Constraint energy minimizing generalized multiscale finite element method for dual continuum model[J]. Communications in Mathematical Sciences, 2020, 18 (3): 663-685. doi: 10.4310/CMS.2020.v18.n3.a4
[19]	Chung E T, Efendiev Y, Leung T, et al. Coupling of multiscale and multi-continuum approaches[J]. GEM-International Journal on Geomathematics, 2017, 8 (1): 9-41. doi: 10.1007/s13137-017-0093-8
[20]	Chung E T, Efendiev Y, Leung W T, et al. Non-local multi-continua upscaling for flows in heterogeneous fractured media[J]. Journal of Computational Physics, 2018, 372: 22-34. doi: 10.1016/j.jcp.2018.05.038
[21]	Li Q, Wang Y, Vasilyeva M. Multiscale model reduction for fluid infiltration simulation through dual-continuum porous media with localized uncertainties[J]. Journal of Computational and Applied Mathematics, 2018, 336: 127-146. doi: 10.1016/j.cam.2017.12.040
[22]	Park J S R, Cheung S W, Mai T, et al. Multiscale simulations for upscaled multi-continuum flows[J]. Journal of Computational and Applied Mathematics, 2020, 374: 112782. doi: 10.1016/j.cam.2020.112782
[23]	Tene M, Al Kobaisi M S, Hajibeygi H. Algebraic multiscale method for flow in heterogeneous porous media with embedded discrete fractures (F-AMS)[J]. Journal of Computational Physics, 2016, 321: 819-845. doi: 10.1016/j.jcp.2016.06.012
[24]	Chung E, Efendiev Y, Hou T Y. Adaptive multiscale model reduction with generalized multiscale finite element methods[J]. Journal of Computational Physics, 2016, 320: 69-95. doi: 10.1016/j.jcp.2016.04.054
[25]	Efendiev Y, Galvis J, Hou T Y. Generalized multiscale finite element methods (GMsFEM)[J]. Journal of Computational Physics, 2013, 251: 116-135. doi: 10.1016/j.jcp.2013.04.045
[26]	Chung E, Efendiev Y, Leung W T. Constraint energy minimizing generalized multiscale finite element method in the mixed formulation[J]. Computational Geosciences, 2018, 22 (3): 677-693. doi: 10.1007/s10596-018-9719-7
[27]	Galvis J, Efendiev Y. Domain decomposition preconditioners for multiscale flows in high-contrast media[J]. Multiscale Modeling & Simulation, 2010, 8 (4): 1461-1483.
[28]	Kim H H, Chung E, Wang J. BDDC and FETI-DP preconditioners with adaptive coarse spaces for three-dimensional elliptic problems with oscillatory and high contrast coefficients[J]. Journal of Computational Physics, 2017, 349: 191-214. doi: 10.1016/j.jcp.2017.08.003
[29]	Li G. On the convergence rates of GMsFEMs for heterogeneous elliptic problems without oversampling techniques[J]. Multiscale Modeling & Simulation, 2019, 17 (2): 593-619.
[30]	Xiao D, Fang F, Pain C C, et al. A parameterized non-intrusive reduced order model and error analysis for general time-dependent nonlinear partial differential equations and its applications[J]. Computer Methods in Applied Mechanics and Engineering, 2017, 317: 868-889. doi: 10.1016/j.cma.2016.12.033
[31]	Brunton S L, Kutz J N. Data-driven Science and Engineering: Machine Learning, DynamicalSystems, and Control[M]. 2nd ed. Cambridge: Cambridge University Press, 2022.
[32]	Hesthaven J S, Rozza G, Stamm B. Certified Reduced Basis Methods for Parametrized Partial Differential Equations[M]. Springer, 2016.
[33]	Quarteroni A, Manzoni A, Negri F. Reduced Basis Methods for Partial Differential Equations: an Introduction[M]. Springer, 2016.
[34]	王青山, 严波, 陈岩, 等. 基于降阶模型和数据驱动的动态结构数字孪生方法[J]. 应用数学和力学, 2023, 44 (7), 757-768. doi: 10.21656/1000-0887.430384 Wang Qingshan, Yan Bo, Chen Yan, et al. A digital twin method for dynamic structures based on reduced order models and data driving[J]. Applied Mathematics and Mechanics, 2023, 44 (7), 757-768. (in Chinese) doi: 10.21656/1000-0887.430384
[35]	Gunzburger M, Jiang N, Schneier M. An ensemble-proper orthogonal decomposition method for the nonstationary Navier-Stokes equations[J]. SIAM Journal on Numerical Analysis, 2017, 55 (1): 286-304. doi: 10.1137/16M1056444
[36]	Luo Y, Wang Z. A multilevel Monte Carlo ensemble scheme for random parabolic PDEs[J]. SIAM Journal on Scientific Computing, 2019, 41 (1): A622-A642. doi: 10.1137/18M1174635
[37]	Gunzburger M, Jiang N, Wang Z. An efficient algorithm for simulating ensembles of parameterized flow problems[J]. IMA Journal of Numerical Analysis, 2019, 39 (3): 1180-1205. doi: 10.1093/imanum/dry029
[38]	Feng X, Lin J, Lorton C. An efficient numerical method for acoustic wave scattering in random media[J]. ASA Journal on Uncertainty Quantification, 2015, 3 (1): 790-822.
[39]	Feng X, Lin J, Lorton C. A multimodes Monte Carlo finite element method for elliptic partial differential equations with random coefficients[J]. International Journal for Uncertainty Quantification, 2016, 6 (5): 429-443. doi: 10.1615/Int.J.UncertaintyQuantification.2016016805
[40]	Zhang S, Yang Z, Guan X. Multi-modes multiscale approach of heat transfer problems in heterogeneous solids with uncertain thermal conductivity[J]. Advances in Applied Mathematics and Mechanics, 2025, 15 (1): 69-93.
[41]	Feng X, Luo Y, Vo L, et al. An efficient iterative method for solving parameter-dependent and random convection-diffusion problems[J]. Journal of Scientific Computing, 2022, 90: 72. doi: 10.1007/s10915-021-01737-z
