An Efficient Operator Splitting Method for Modified Allen-Cahn Equations With Mean Curvature Terms

Cao Zihan; Wu Zhe; Zhai Shuying

doi:10.21656/1000-0887.460107

Volume 47 Issue 7

Jul. 2026

Turn off MathJax

Article Contents

Article Navigation > Applied Mathematics and Mechanics > 2026 > 47(7): 924-935

Cao Zihan, Wu Zhe, Zhai Shuying. An Efficient Operator Splitting Method for Modified Allen-Cahn Equations With Mean Curvature Terms[J]. Applied Mathematics and Mechanics, 2026, 47(7): 924-935. doi: 10.21656/1000-0887.460107

Citation:

PDF( 2001 KB)

An Efficient Operator Splitting Method for Modified Allen-Cahn Equations With Mean Curvature Terms

doi: 10.21656/1000-0887.460107

School of Mathematical Sciences, Huaqiao University, Quanzhou, Fujian 362021, P. R. China

Received Date: 2025-05-29
Rev Recd Date: 2025-07-30
Publish Date: 2026-07-01

Abstract

Abstract

The modified Allen-Cahn equation with the mean curvature source term can effectively model curvature-driven physical processes. However, the nonlinear term and gradient magnitude make it difficult to design efficient numerical schemes. An efficient numerical scheme was proposed for solving the equation. Based on the Strang operator splitting method, the original equation was discretized in time into three subproblems: the nonlinear equation was solved analytically; the mean curvature equation was discretized using the second-order Runge-Kutta method combined with central differences to establish a fully discrete explicit scheme, while the heat equation was discretized with the Crank-Nicolson method and solved via the alternating direction implicit (ADI) fast scheme. Theoretical analysis shows that, the proposed scheme achieves second order convergence accuracy. Finally, numerical experiments were presented to validate the convergence rate and effectiveness of the scheme.
- modified Allen-Cahn equation,
- operator splitting scheme,
- ADI,
- convergence analysis

(Recommended by Zhao Jingjun, Member of the Editorial Board of AMM)

FullText(HTML)

References(33)

References

[1]	Allen S M, Cahn J W. A microscopic theory for antiphase boundary motion and its application to antiphase domain coarsening[J]. Acta Metallurgica, 1979, 27 (6): 1085-1095. doi: 10.1016/0001-6160(79)90196-2
[2]	Yue P, Feng J J, Liu C, et al. Diffuse-interface simulations of drop coalescence and retraction in viscoelastic fluids[J]. Journal of Non-Newtonian Fluid Mechanics, 2005, 129 (3): 163-176. doi: 10.1016/j.jnnfm.2005.07.002
[3]	Kim J. Phase-field models for multi-component fluid flows[J]. Communications in Computational Physics, 2012, 12 (3): 613-661. doi: 10.4208/cicp.301110.040811a
[4]	Kobayashi R. Modeling and numerical simulations of dendritic crystal growth[J]. Physica D: Nonlinear Phenomena, 1993, 63 (3/4): 410-423.
[5]	Li Y, Lee H G, Kim J. A fast, robust, and accurate operator splitting method for phase-field simulations of crystal growth[J]. Journal of Crystal Growth, 2011, 321 (1): 176-182. doi: 10.1016/j.jcrysgro.2011.02.042
[6]	Wheeler A A, Boettinger W J, McFadden G B. Phase-field model for isothermal phase transitions in binary alloys[J]. Physical Review A, 1992, 45 (10): 7424-7439. doi: 10.1103/PhysRevA.45.7424
[7]	Elliott C M, Stinner B. Computation of two-phase biomembranes with phase dependent material parameters using surface finite elements[J]. Communications in Computational Physics, 2013, 13 (2): 325-360. doi: 10.4208/cicp.170611.130112a
[8]	Cohen D S, Murray J D. A generalized diffusion model for growth and dispersal in a population[J]. Journal of Mathematical Biology, 1981, 12 (2): 237-249. doi: 10.1007/BF00276132
[9]	Wang J, Li Y, Choi Y, et al. Fast and accurate smoothing method using a modified Allen-Cahn equation[J]. Computer-Aided Design, 2020, 120: 102804. doi: 10.1016/j.cad.2019.102804
[10]	Hazewinkel M, Kaashoek J F, Leynse B. Pattern formation for a one dimensional evolution equation based on thom's river basin model[M]//Kilmister C W. Disequilibrium and Self-Organisation. Dordrecht: Springer Netherlands, 1986: 23-46.
[11]	Wang J, Lee C, Lee H G, et al. Phase-field modeling and numerical simulation for ice melting[J]. Numerical Mathematics: Theory, Methods and Applications, 2021, 14 (2): 540-558. doi: 10.4208/nmtma.OA-2020-0023
[12]	Xu J, Li Y, Wu S, et al. On the stability and accuracy of partially and fully implicit schemes for phase field modeling[J]. Computer Methods in Applied Mechanics and Engineering, 2019, 345: 826-853. doi: 10.1016/j.cma.2018.09.017
[13]	Feng X, Tang T, Yang J. Stabilized Crank-Nicolson/Adams-Bashforth schemes for phase field models[J]. East Asian Journal on Applied Mathematics, 2013, 3 (1): 59-80. doi: 10.4208/eajam.200113.220213a
[14]	He Y, Liu Y, Tang T. On large time-stepping methods for the Cahn-Hilliard equation[J]. Applied Numerical Mathematics, 2007, 57 (5/6/7): 616-628.
[15]	Shen J, Yang X. Numerical approximations of Allen-Cahn and Cahn-Hilliard equations[J]. Discrete and Continuous Dynamical Systems, 2010, 28 (4): 1669-1691. doi: 10.3934/dcds.2010.28.1669
[16]	Hochbruck M, Ostermann A. Explicit exponential Runge-Kutta methods for semilinear parabolic problems[J]. SIAM Journal on Numerical Analysis, 2005, 43 (3): 1069-1090. doi: 10.1137/040611434
[17]	Hochbruck M, Ostermann A. Exponential integrators[J]. Acta Numerica, 2010, 19: 209-286. doi: 10.1017/S0962492910000048
[18]	Tang T, Yang J. Implicit-explicit scheme for the Allen-Cahn equation preserves the maximum principle[J]. Journal of Computational Mathematics, 2025, 34 (5): 451-461.
[19]	Shen J, Tang T, Yang J. On the maximum principle preserving schemes for the generalized Allen-Cahn equation[J]. Communications in Mathematical Sciences, 2016, 14 (6): 1517-1534. doi: 10.4310/CMS.2016.v14.n6.a3
[20]	Shen J, Xu J, Yang J. A new class of efficient and robust energy stable schemes for gradient flows[J]. SIAM Review, 2019, 61 (3): 474-506. doi: 10.1137/17M1150153
[21]	Strang G. On the construction and comparison of difference schemes[J]. SIAM Journal on Numerical Analysis, 1968, 5 (3): 506-517. doi: 10.1137/0705041
[22]	Zhai S, Wang D, Weng Z, et al. Error analysis and numerical simulations of strang splitting method for space fractional nonlinear Schrödinger equation[J]. Journal of Scientific Computing, 2019, 81 (2): 965-989. doi: 10.1007/s10915-019-01050-w
[23]	Zhai S, Weng Z, Yang Y. A high order operator splitting method based on spectral deferred correction for the nonlocal viscous Cahn-Hilliard equation[J]. Journal of Computational Physics, 2021, 446: 110636. doi: 10.1016/j.jcp.2021.110636
[24]	Yang J, Kang S, Kwak S, et al. The Allen-Cahn equation with a space-dependent mobility and a source term for general motion by mean curvature[J]. Journal of Computational Science, 2024, 77: 102252. doi: 10.1016/j.jocs.2024.102252
[25]	Cao Z, Weng Z, Zhai S. An effective operator splitting scheme for general motion by mean curvature using a modified Allen-Cahn equation[J]. Applied Mathematics Letters, 2025, 163: 109472. doi: 10.1016/j.aml.2025.109472
[26]	Zhai S, Weng Z, Feng X, et al. Stability and error estimate of the operator splitting method for the phase field crystal equation[J]. Journal of Scientific Computing, 2021, 86: 8. doi: 10.1007/s10915-020-01386-8
[27]	崔晨, 吴哲, 翟术英. 非局部守恒Allen-Cahn方程的高效算子分裂格式[J]. 华侨大学学报(自然科学版), 2022, 43 (5): 698-704. Cui Chen, Wu Zhe, Zhai Shuying. Effective operator splitting scheme for conservative nonlocal Allen-Cahn equation[J]. Journal of Huaqiao University (Natural Science), 2022, 43 (5): 698-704. (in Chinese)
[28]	Qiao Y Y, Zhai S Y, Feng X L. An operator splitting method for image inpainting based on the Allen-Cahn equation[J]. Chinese Journal of Engineering Mathematics, 2018, 35 (6): 722-732.
[29]	Weng Z, Zhai S, Dai W, et al. Stability and error estimates of Strang splitting method for the nonlocal ternary conservative Allen-Cahn model[J]. Journal of Computational and Applied Mathematics, 2024, 441: 115668. doi: 10.1016/j.cam.2023.115668
[30]	Zhai S, Weng Z, Mo Y, et al. Energy dissipation and maximum bound principle preserving scheme for solving a nonlocal ternary Allen-Cahn model[J]. Computers & Mathematics With Applications, 2024, 155: 150-164.
[31]	吴龙渊, 汪精英, 翟术英. 求解二维Allen-Cahn方程的两种ADI格式[J]. 华侨大学学报(自然科学版), 2019, 40 (3): 412-420. Wu Longyuan, Wang Jingying, Zhai Shuying. Two ADI schemes for solving two-dimensional Alleb-Cahn equations[J]. Journal of Huaqiao University (Natural Science), 2019, 40 (3): 412-420. (in Chinese)
[32]	D'Yakonov Y G. Difference schemes with a separable operator for general second order parabolic equations with variable coefficients[J]. USSR Computational Mathematics and Mathematical Physics, 1964, 4 (2): 92-110. doi: 10.1016/0041-5553(64)90108-9
[33]	Du Q, Ju L, Li X, et al. Stabilized linear semi-implicit schemes for the nonlocal Cahn-Hilliard equation[J]. Journal of Computational Physics, 2018, 363: 39-54. doi: 10.1016/j.jcp.2018.02.023
