多段翼附壁效应环量控制RANS气动特性分析

杜一鸣; 李志浩; 王浩; 黄龙太; 高攀

doi:10.21656/1000-0887.460006

多段翼附壁效应环量控制RANS气动特性分析

doi: 10.21656/1000-0887.460006

杜一鸣^1, ,,
李志浩^1,,
王浩²,
黄龙太³,
高攀³

1.
沈阳航空航天大学航空宇航学院，沈阳 110136
2.
中国航空研究院，北京 100029
3.
中国特种飞行器研究所，湖北荆门 431800

基金项目:

国家自然科学基金青年项目 12202284

详细信息

作者简介:
李志浩(2000—)，男，硕士生(E-mail: lzh_200003013014@163.com)

通讯作者:
杜一鸣(1990—)，男，副教授，博士，硕士生导师(通信作者. E-mail: duyiming@sau.edu.cn)

中图分类号: O354
计量
- 文章访问数: 38
- HTML全文浏览量: 11
- PDF下载量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2025-01-13
- 修回日期: 2025-11-11
- 刊出日期: 2026-05-01

Aerodynamic Characteristic Analysis on Coanda Effects of Multi-Element Airfoils Under Circulation Control Based on RANS

1.
College of Aerospace Engineering, Shenyang Aerospace University, Shenyang 110136, P. R. China
2.
Chinese Aeronautical Establishment, Beijing 100029, P. R. China
3.
China Special Vehicle Research Institute, Jingmen, Hubei 431800, P. R. China

摘要

摘要: 将传统机械式增升装置与先进环量控制技术结合有望改进现有飞行器起降性能. 本文基于Reynolds平均Navier-Stokes(RANS)方法，以二维翼型NLR-7301两段翼为研究对象，分别在主翼和襟翼部位施加环量控制，系统分析了射流喷口位置、高度和动量系数对多段翼气动特性的影响. 研究表明，喷口位置决定了基础气动力水平，喷口靠后会导致Coanda型面过小，附壁效应微弱；而喷口靠前则容易在下表面引起较大分离，降低增升效果. 升力系数基本随射流喷口高度减小和动量系数增大而增大，但存在多参数影响的非线性效应. 喷口高度较小时增升效果较好，过大的喷口射流速度较低，卷吸引射效应减弱，甚至会导致主翼环量控制失效. 计算结果显示，对于NLR-7301两段翼主翼或襟翼环量控制，动量系数0.03是一个较为合适的选择，继续增大会引起控制翼面下表面较大分离，增升效率降低. 从压力分布上看，环量控制能够抬高主翼前缘吸力峰，改善上表面吸力和下表面压力，同时主翼射流的卷吸引射作用有助于消除襟翼后缘边界层分离. 此外，环量控制在三维条件下仍能有效改善机翼气动性能，但其控制效果受展向流动影响，从翼根至翼尖逐渐衰减. 以上结论可为多段翼环量控制设计提供参考，在实际应用中需要通过数值优化寻找控制参数的最优组合，并兼顾升阻特性.
- 环量控制 /
- 附壁效应 /
- 多段翼 /
- RANS /
- 动量系数 /
- 气动特性
Abstract: Combining traditional high lift devices with circulation control is expected to improve the takeoff and landing performance of aircraft. Based on the Reynolds averaged Navier-Stokes (RANS) method, the 2D NLR-7301 2-segment airfoil was taken as the research object. The circulation control was applied to the main element and the flap respectively, and the effects of jet positions, heights, and momentum coefficients on the aerodynamic characteristics of the multi-segment airfoil were systematically investigated. The results show that, the position of the jet determines the basic aerodynamic force. For a too far backward jet position, the Coanda surface will be too small to yield the wall attachment effect. Conversely, for a too far forward jet position, significant separation will easily happen on the lower surface, to reduce the lift-enhancement effect. The lift coefficient generally increases with the decrease of the jet height and the increase of the momentum coefficient, but there is a nonlinear effect by multiple parameters. A smaller jet height can bring a better lift increasement. For high jet heights, the jet velocity is low, to weaken the entrainment effect and potentially cause circulation control failure of the main element. For the circulation control of either the main element or the flap of NLR-7301, 0.03 is an appropriate momentum coefficient, and further increase will cause significant separation of the lower surface, and reduce the efficiency of lift-enhancement. From the perspective of pressure distribution, the circulation control can elevate the suction peak at the leading edge of the main element, and improve the upper surface suction and lower surface pressure. At the same time, the entrainment effect of the main element jet flow helps to eliminate the boundary layer separation at the trailing edge of the flap. Furthermore, the circulation control can still effectively enhance the aerodynamic performance of the wing under 3D conditions. However, its control effect is affected by the spanwise flow and gradually diminishes from the wing root to the tip. The above conclusions provide a reference for the design of the circulation control of multi-element airfoils. In practical applications, numerical optimization is required to find the optimal combination of control parameters, in view of both lift and drag characteristics.
- circulation control /
- wall attachment effect /
- multi-element airfoil /
- RANS /
- momentum coefficient /
- aerodynamic characteristics

HTML全文

图 1 S809翼型环量控制外形对比及计算网格

注为了解释图中的颜色，读者可以参考本文的电子网页版本，后同.

Figure 1. The geometry comparison and computational grids of S809 and S809-CC

下载: 全尺寸图片幻灯片

图 2 S809和S809-CC翼型表面压力分布与参考结果^[36]的对比

Figure 2. Surface pressure distribution comparisons of S809 and S809-CC with ref. [36]

下载: 全尺寸图片幻灯片

图 3 S809翼型环量控制前后流动特性对比

Figure 3. Comparisons of flow characteristics before and after circulation control of the S809 airfoil

下载: 全尺寸图片幻灯片

图 4 NLR-7301多段翼及其计算网格

Figure 4. The geometry and computational grid of the NLR-7301 multi-element airfoil

下载: 全尺寸图片幻灯片

图 5 NLR-7301多段翼构型压力分布

Figure 5. The pressure distributions of NLR-7301 multi-elementairfoil

下载: 全尺寸图片幻灯片

图 6 NLR-7301环量控制构型及计算网格

Figure 6. The schematic diagram and grid of NLR-7301 with circulation control

下载: 全尺寸图片幻灯片

图 7 力系数收敛曲线

Figure 7. The convergence history of force coefficients

下载: 全尺寸图片幻灯片

图 8 NLR-7301-CC_flap气动特性变化曲线

Figure 8. The aerodynamic characteristic variation curves of NLR-7301-CC_flap

下载: 全尺寸图片幻灯片

图 9 NLR-7301-CC_flap翼型不同开口位置下的流场图

Figure 9. The flow fields of NLR-7301-CC_flap in different positions of the jet

下载: 全尺寸图片幻灯片

图 10 不同动量系数下NLR-7301-CC_flap翼型流场图

Figure 10. The flow fields of NLR-7301-CC_flap under different momentum coefficients

下载: 全尺寸图片幻灯片

图 11 NLR-7301-CC_flap翼型流场图(c_j=0.7c_flap，h=0.000 15c)

Figure 11. The flow field of NLR-7301-CC_flap (c_j=0.7c_flap, h=0.000 15c)

下载: 全尺寸图片幻灯片

图 12 NLR-7301-CC_flap环量控制前后压力分布

Figure 12. The pressure distributions before and after circulation control of NLR-7301-CC_flap

下载: 全尺寸图片幻灯片

图 13 NLR-7301-CC_main翼型气动特性变化曲线(c_j=0.9c_main)

Figure 13. The aerodynamic characteristic variations of NLR-7301-CC_main (c_j=0.9c_main)

下载: 全尺寸图片幻灯片

图 14 不同动量系数的流场图(h=0.001c)

Figure 14. The flow fields with different momentum coefficients (h=0.001c)

下载: 全尺寸图片幻灯片

图 15 不同喷口高度对应流场图(C_μ=0.03)

Figure 15. The flow fields with different jet heights (C_μ=0.03)

下载: 全尺寸图片幻灯片

图 16 NLR-7301-CC_main环量控制前后压力分布图

Figure 16. The pressure distributions before and after circulation control of NLR-7301-CC_main

下载: 全尺寸图片幻灯片

图 17 机翼模型及计算网格

Figure 17. The wing model and computational mesh

下载: 全尺寸图片幻灯片

图 18 3D机翼气动特性变化曲线

Figure 18. The aerodynamic characteristic variations of the 3D wing

下载: 全尺寸图片幻灯片

图 19 3D机翼气动特性变化曲线

Figure 19. The aerodynamic characteristic variations of the 3D wing

下载: 全尺寸图片幻灯片

图 20 机翼不同站位流场图(y/b=0.1，0.5，0.9)

Figure 20. The flow fields of different wing positions (y/b=0.1, 0.5, 0.9)

下载: 全尺寸图片幻灯片

表 1 NLR-7301多段翼构型的气动力系数

Table 1. Aerodynamic coefficients of the NLR-7301 multi-element airfoil

α/(°)	turbulence model	C_L	C_D
6.0	k-ω SST	2.399	0.030 5
	γ-Re_θt	2.455	0.026 5
	ref. [44]	2.499	0.027 4
	exp	2.416	0.022 9
13.1	k-ω SST	3.020	0.066 5
	γ-Re_θt	3.168	0.055 8
	ref. [44]	3.272	0.051 2
	exp	3.141	0.044 5

下载: 导出CSV

参考文献(44)

[1]	朱自强, 吴宗成. 环量控制技术研究[J]. 航空学报, 2016, 37(2): 411-428. ZHU Ziqiang, WU Zongcheng. Study of the circulation control technology[J]. Acta Aeronautica et Astronautica Sinica, 2016, 37(2): 411-428. (in Chinese)
[2]	谢川, 徐超, 周丹发, 等. 带襟翼导轨翼肋后缘尺寸-拓扑综合优化的摄动神经网络代理模型法[J]. 应用数学和力学, 2024, 45(1): 61-71. doi: 10.21656/1000-0887.440033 XIE Chuan, XU Chao, ZHOU Danfa, et al. The perturbation neural network surrogate model method for size-topology synthetical optimization of wing rib trailing edges with flap tracks[J]. Applied Mathematics and Mechanics, 2024, 45(1): 61-71. (in Chinese) doi: 10.21656/1000-0887.440033
[3]	JONES G, VIKEN S, WASHBURN A, et al. An active flow circulation controlled flap concept for general aviation aircraft applications[C]// 1 st Flow Control Conference. St Louis, Missouri, 2002: 3157.
[4]	张艳华, 张登成, 周章文, 等. 基于环量控制的虚拟舵面飞行器概念与设计综述[J]. 航空学报, 2024, 45(6): 629608. ZHANG Yanhua, ZHANG Dengcheng, ZHOU Zhangwen, et al. Concept and design of virtual rudder surface aircraft based on circulation control: review[J]. Acta Aeronautica et Astronautica Sinica, 2024, 45(6): 629608. (in Chinese)
[5]	ENGLAR R J. STOL: the potential of the circulation control wing concept[J]. Naval Engineers Journal, 1979, 91(2): 99-108. doi: 10.1111/j.1559-3584.1979.tb03869.x
[6]	ENGLAR R J. Circulation control pneumatic aerodynamics: blown force and moment augmentation and modification; past, present and future[C]//Fluids 2000 Conference and Exhibit. Denver, CO, 2000: 2541.
[7]	PUGLIESE A J, ENGLAR R J. Flight testing of the circulation control wing: AIAA-1979-1791[R]. Reston: AIAA, 1979.
[8]	ENGLAR R J. Development of the A-6/circulation control wing-flight demonstrator configuration: DTNSRDC/ASEL-79/01[R]. Maryland: DTNSRDC, 1979.
[9]	NATO AVT-239 task group: flight demonstration of fluidic flight controls on the MAGMA subscale demonstrator aircraft[C]//AIAA Scitech 2019 Forum. San Diego, California, 2019: 0282.
[10]	SHEARWOOD T R, NABAWY M R, CROWTHER W J, et al. Three-axis control of tailless aircraft using fluidic actuators: MAGMA case study[C]//AIAA Aviation 2021 Forum. Virtual Event, 2021: 2530.
[11]	孙全兵, 史志伟, 耿玺, 等. 基于主动流动控制技术的无舵面飞翼布局飞行器姿态控制[J]. 航空学报, 2020, 41(12): 185-194. SUN Quanbing, SHI Zhiwei, GENG Xi, et al. Attitude control of flying wing aircraft without control surfaces based on active flow control[J]. Acta Aeronautica et Astronautica Sinica, 2020, 41(12): 185-194. (in Chinese)
[12]	王磊, 杜海, 李秋实, 等. 环量控制机翼增升及滚转控制特性研究[J]. 空气动力学学报, 2021, 39(1): 43-51. WANG Lei, DU Hai, LI Qiushi, et al. Research on the lift-enhancement and roll control characteristics of a circulation control wing[J]. Acta Aerodynamica Sinica, 2021, 39(1): 43-51. (in Chinese)
[13]	夏智勋, 罗振兵. 合成射流激励器射流矢量控制的物理因素[J]. 应用数学和力学, 2007, 28(7): 811-823. http://www.applmathmech.cn/article/id/937 XIA Zhixun, LUO Zhenbing. Physical factors of a primary jet vectoring control using synthetic jet actuators[J]. Applied Mathematics and Mechanics, 2007, 28(7): 811-823. (in Chinese) http://www.applmathmech.cn/article/id/937
[14]	ZHAO Z J, DENG X, LUO Z B, et al. Flight control of a flying wing aircraft based on circulation control using synthetic jet actuators[J]. Chinese Journal of Aeronautics, 2023, 36(10): 152-164. doi: 10.1016/j.cja.2023.08.016
[15]	LI Y, WANG X, ZHANG D. Control strategies for aircraft airframe noise reduction[J]. Chinese Journal of Aeronautics, 2013, 26(2): 249-260. doi: 10.1016/j.cja.2013.02.001
[16]	邵帅, 郭正, 贾高伟, 等. 宽速域飞翼布局后缘射流滚转控制研究[J]. 国防科技大学学报, 2022, 44(4): 101-115. SHAO Shuai, GUO Zheng, JIA Gaowei, et al. Roll control study of flying wing based on trailing-edge jet at wide speed range[J]. Journal of National University of Defense Technology, 2022, 44(4): 101-115. (in Chinese)
[17]	MABEY D G. Analysis and correlation of data on pressure fluctuations in separated flow[J]. Journal of Aircraft, 1972, 9(9): 642-645. doi: 10.2514/3.59053
[18]	MILHOLEN W E, JONES G S, CHAN D T, et al. Enhancements to the FAST-MAC circulation control model and recent high-Reynolds number testing in the national transonic facility[C]// 31 st AIAA Applied Aerodynamics Conference. San Diego, CA, 2013: 2794.
[19]	JONES G S, MILHOLEN W E, CHAN D T, et al. A sweeping jet application on a high Reynolds number semi-span supercritical wing configuration[C]// 35 th AIAA Applied Aerodynamics Conference. Denver, Colorado, 2017: 3044.
[20]	WOOD N, NIELSEN J. Circulation control airfoils: past, present, future[C]// 23 rd Aerospace Sciences Meeting. Reno, NV, 1985: 204.
[21]	ABRAMSON J, ROGERS E. High-speed characteristics of circulation control airfoils[C]// 21 st Aerospace Sciences Meeting. Reno, NV, 1983: 265.
[22]	宋彦萍, 陈焕龙, 李亚超, 等. 射流压力和高度对环量控制涡轮叶栅性能影响[J]. 工程热物理学报, 2011, 32(3): 399-402. SONG Yanping, CHEN Huanlong, LI Yachao, et al. Effect of jet pressure and jet height on the performance of circulation control turbine cascade[J]. Journal of Engineering Thermophysics, 2011, 32(3): 399-402. (in Chinese)
[23]	宋彦萍, 陈焕龙, 李亚超, 等. 柯恩达表面形状对环量控制涡轮叶型性能影响[J]. 工程热物理学报, 2012, 33(1): 43-46. SONG Yanping, CHEN Huanlong, LI Yachao, et al. Effect of Coanda surface shape on the performance of circulation control turbine cascade[J]. Journal of Engineering Thermophysics, 2012, 33(1): 43-46. (in Chinese)
[24]	张艳华, 张登成, 胡孟权, 等. 环量控制对翼型气动特性的作用机理[J]. 空军工程大学学报(自然科学版), 2015, 16(1): 10-13. ZHANG Yanhua, ZHANG Dengcheng, HU Mengquan, et al. Study on aerodynamic mechanism of circulation control airfoil[J]. Journal of Air Force Engineering University (Natural Science Edition), 2015, 16(1): 10-13. (in Chinese)
[25]	郑无计, 张登成, 张艳华, 等. 超临界翼型射流环量控制的数值计算[J]. 航空计算技术, 2014, 44(3): 92-95. ZHENG Wuji, ZHANG Dengcheng, ZHANG Yanhua, et al. Numerical calculation of circulation control by blowing on supercritical airfoil[J]. Aeronautical Computing Technique, 2014, 44(3): 92-95. (in Chinese)
[26]	乔晨亮, 许和勇, 叶正寅. 钝后缘风力机翼型的环量控制研究[J]. 力学学报, 2019, 51(1): 135-145. QIAO Chenliang, XU Heyong, YE Zhengyin. Circulation control on wind turbine airfoil with blunt trailing edge[J]. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(1): 135-145. (in Chinese)
[27]	XU H Y, QIAO C L, YANG H Q, et al. Active circulation control on the blunt trailing edge wind turbine airfoil[J]. AIAA Journal, 2017, 56(2): 554-570.
[28]	SHREWSBURY G. Analysis of circulation control airfoils using an implicit Navier-Stokes solver[C]// 23 rd Aerospace Sciences Meeting. Reno, NV, 1985: 171.
[29]	SLOMSKI J, GORSKI J, MILLER R, et al. Numerical simulation of circulation control airfoils as affected by different turbulence models[C]// 40 th AIAA Aerospace Sciences Meeting & Exhibit. Reno, NV, 2002: 851.
[30]	MCGOWAN G, RUMSEY C, SWANSON R, et al. A three-dimensional computational study of a circulation control wing[C]// 3 rd AIAA Flow Control Conference. San Francisco, California, 2006: 3677.
[31]	SWANSON R C, RUMSEY C L. Numerical issues for circulation control calculations[C]// 3 rd AIAA Flow Control Conference. San Francisco, California, 2006: 3008.
[32]	SWANSON R C, RUMSEY C L. Computation of circulation control airfoil flows[J]. Computers & Fluids, 2009, 38(10): 1925-1942.
[33]	KRIST S L, BIEDRON R T, RUMSEY C L. CFL3D user's manual-Ver. 5.0 (2nd edition)[Z]. Hampton, Virginia: NASA Langley Research Center, NASA/TM-1998-208444, 1998.
[34]	杜一鸣. 涡粘性湍流模型修正与三维边界层转捩预测方法研究[D]. 西安: 西北工业大学, 2021. DU Yiming. Research on corrections of RANS eddy-viscosity turbulence model and prediction method of three-dimensional boundary-layer transition[D]. Xi'an: Northwestern Polytechnical University, 2021. (in Chinese)
[35]	SOMERS D M. Design and experimental results for the S809 airfoil[R]. Colorado: National Renewable Energy Laboratory, 1997.
[36]	苏子昂, 孙晓晶. S809翼型环量控制的射流参数研究[J]. 太阳能学报, 2020, 41(7): 359-366. SU Ziang, SUN Xiaojing. Numerical study on effects of various parameters on aerodynamic characteristics of S809 airfoil with circulation flow control[J]. Acta Energiae Solaris Sinica, 2020, 41(7): 359-366. (in Chinese)
[37]	CODER J G. Standard test cases for transition model verification and validation in computational fluid dynamics[C]// 56 th AIAA Aerospace Sciences Meeting. Kissimmee, Florida, 2018.
[38]	MENTER F R. Two-equation eddy-viscosity turbulence models for engineering applications[J]. AIAA Journal, 1994, 32(8): 1598-1605. doi: 10.2514/3.12149
[39]	白亚磊, 马兴宇, 明晓. 风力机叶型增升及叶尖流动控制研究[J]. 应用数学和力学, 2011, 32(7): 774-784. doi: 10.3879/j.issn.1000-0887.2011.07.002 BAI Yalei, MA Xingyu, MING Xiao. Lift enhancement of the airfoil and tip flow control for wind turbine[J]. Applied Mathematics and Mechanics, 2011, 32(7): 774-784. (in Chinese) doi: 10.3879/j.issn.1000-0887.2011.07.002
[40]	VAN DEN BERG B, GOODEN J H M. Low-speed surface pressure and boundary layer measurement data for the NLR-7301 airfoil section with trailing edge flap: AGARD AR-303[R]. Selection of Experimental Test Cases for the Validation of CFD Codes, 1994.
[41]	KOCH J R, HOUSMAN J A, HOSSEINI S S. Microjet angle sensitivity for active flow control on multi-element high-lift systems[C]//AIAA Aviation 2023 Forum. San Diego, CA, 2023: 4307.
[42]	LANGTRY R B, MENTER F R. Correlation-based transition modeling for unstructured parallelized computational fluid dynamics codes[J]. AIAA Journal, 2009, 47(12): 2894-2906. doi: 10.2514/1.42362
[43]	RUMSEY C L, YING S X. Prediction of high lift: review of present CFD capability[J]. Progress in Aerospace Sciences, 2002, 38(2): 145-180. doi: 10.1016/S0376-0421(02)00003-9
[44]	李立, 麻蓉, 梁益华. NLR-7301高升力翼型绕流评估计算[J]. 航空计算技术, 2014, 44(3): 12-15. LI Li, MA Rong, LIANG Yihua. CFD validation for high-lift flow over NLR-7301 airfoil[J]. Aeronautical Computing Technique, 2014, 44(3): 12-15. (in Chinese)
